Electric heating constant temperature blast drying oven and supporting equipment for sale
Electrothermal constant temperature blast drying oven is a commonly used equipment, mainly used to dry samples, and can also provide the temperature environment required for experiments. For industrial and mining enterprises, colleges and universities, biological products, food processing, agricultural science and technology, chemical and pharmaceutical, medical units and various laboratories for powder drying and baking under vacuum conditions. It is especially suitable for drying of heat-sensitive, easily decomposed, easily oxidized substances and articles with complex components.
The electric heating constant temperature blast drying box adopts the electric heating method to carry out the blast circulation drying test. The hot air is blown out by the circulating fan to ensure the temperature balance in the box. The air conditioning method is adopted to force the internal circulation ventilation to balance the temperature. The drying box adopts PT100 platinum resistance temperature sensor and digital temperature regulator for temperature control, which is sensitive to temperature control, easy to operate and reliable in performance. The figures directly display the working temperature, which is intuitive and easy to read.
DZF-6500 vacuum drying oven
Product details:
1. Multi-gear design, the distance between the load brackets can be flexibly adjusted up and down;
2. High temperature resistant silicone sealing ring to improve the sealing performance of the box;
3. The studio adopts galvanized inner tank or sanitary stainless steel plate, which is strong anti-corrosion;
4. The bulletproof double-layer temperature-resistant tempered glass window makes your observation work clear at a glance;
5. The double-screen digital display panel adjusted by the touch key makes your setting or reading more intuitive;
technical parameter:
Power Supply: 220V 50/60HZ
Shell Material: Spray-plant Anti-corrosion
Liner Material: 304 Stainless Steel
Temp. Range: RT+10~300℃
Temp.Stability: ±1.0℃
Temp.Analysis: 1.0℃
Working Temp.: +5~40℃
Input Power: 4000W
Chamber Capacity: 620L
Inner Dimension: 840*600*1300mm
Overall Dimension: 980*800*1710mm
Shelves: 4pcs
Temp Range: 1-9999min
*The performance parameter test is under no-load conditions, no strong magnetism and no vibration: the ambient temperature is 20°C, the ambient humidity is 50%RH, and the test temperature point is 100°C.
1. The inside of the box is made of mirror stainless steel argon arc welding, and the outside of the box is made of high-quality steel plate, which is beautiful and novel in appearance.
2. The microcomputer P.I.D temperature controller with over-temperature deviation protection and digital display is adopted, with timing function, and the temperature is accurate and reliable.
3. The hot air circulation system is composed of fans and suitable air ducts that can operate continuously at high temperature, so as to improve the uniform temperature in the work room.
4. The new type of synthetic silicon sealing strip is adopted, which can run at high temperature for a long time, has a long service life and is easy to replace.
5. The air intake and exhaust volume in the box can be adjusted from the temperature control panel.
6. Independent temperature limit alarm system, it will be automatically interrupted when the temperature exceeds the limit to ensure the safe operation of the experiment without accidents. (optional)
7. It can be equipped with a printer or RS485 interface, which can be used to connect to a printer or computer, and can record the changes of temperature parameters. (optional)
DZF-6210 vacuum drying oven
After-sales service
1. The equipment is guaranteed for one year, lifetime service, and free replacement of parts that are not artificially damaged within one year;
2. During the warranty period, the artificially damaged parts will be replaced at the purchase (processing) price;
3. Continue to provide users with high-quality technical services outside the warranty period, and enjoy preferential treatment for purchasing spare parts;
4. Remote technical consultation and free installation video are available.
5. Overseas training services for technical engineers can be provided.
The above are the parameters of the electric heating constant temperature blast drying oven. We also have supporting products: AM series diaphragm pumps and other equipment. If you have needs, you can contact Zhengzhou Keda Machinery Equipment Co., Ltd. For decades, Zhengzhou Keda Machinery Equipment Co., Ltd. has been committed to the production and manufacture of laboratory instruments and pipe fittings. If you want to know about our products, or are interested in purchasing our instruments, please contact us, we will be happy to help you.
